Gossip-Based High Availability for Solana Validators

It’s 2:30 AM and the unmistakable sound of your PagerDuty alarm shakes you and the whole house from a deep sleep. You rub your eyes while feeling for your phone and pick it up to see it’s informing you your Solana validator is down. You stumble your way to your computer to begin a groggy attempt at cobbling together muscle memory commands at the keyboard to get things fixed knowing every ~400ms that goes by you’re missing out on rewards. GLHF!

If this or similar sounds familiar to you, you’ve likely had experience running systems on networks that demand high uptime and those often call for high availability (HA) solutions to handle unexpected outages automatically, quickly and gracefully. Solana is no exception, where a primary validator outage can cause (at best) minutes of missed rewards and potential network degradation — an age in Solana time. While failover and HA tools exist, they either lack automation or require extra dependencies and infrastructure that can introduce single points of failure and operational complexity.

To address this challenge, we developed solana-validator-ha — a gossip-based high availability manager that enables validators to automatically detect and monitor peers, and coordinate failover decisions using nothing but the Solana network.

Below is an example of a real automatic failover on a two-node cluster where a backup validator detects a primary’s outage and automatically takes over as the active (voting) leader, while the primary ensures it comes back as passive (non-voting):

Backup validator (takes over as active after primary outage)

Primary validator (suffers outage, becomes passive)

The Solution

After initial consideration we arrived at the following desirable properties for an HA tool:

1. Standalone — we have experience running open source and paid tools for HA and have no appetite to add operational complexity and single points of failure for this use case, we wanted a standalone program that requires nothing but the Solana network.
2. Configurable — the tool should be simple to run and easy to configure by the operator since we all do things slightly differently and run under different conditions.
3. Safe(ish) — as much as possible, build in guardrails to prevent the tool from making a bad situation worse, or make a good one bad (though DYOR before letting it loose on your nodes).

While operators typically run clusters with two validators (one primary and one backup), solana-validator-ha supports clusters of two or more validators. At a high level it runs the following steps on a synchronized loop across all nodes in the cluster:

1. Peer detection — Query gossip for IPs declared in its configuration file and store a snapshot of their role (active or passive) based on their identity and state (available, missing or unreachable). Gossip entries by themselves aren’t reliable for HA purposes so the program only stores a node in a gossip state snapshot if it can confirm it can be reached on its advertised port.

2. Leaderless detection — An active discovered peer is crowned the leader and no failover is required. The absence of a leader for a configurable amount of time causes it to trigger a configurable command to ensure it stays passive while existing healthy passive nodes begin evaluating whether they should take over as active.

3. Self-healing — Passive nodes wait for a configurable number of confirmations that a leader is lost and wait a pre-determined amount of time before choosing to self-promote to active using a configurable command. The promotion delay prevents multiple nodes racing to become active at the same time.

More details on the inner workings are available at the repository. The default settings we have found to be reliable on nodes this program has been deployed on and has saved our bacon 🐖 already.

Implementation

Though it’s possible to run from the terminal, operators may find it best to run solana-validator-ha as a systemd service that runs the command:

solana-validator-ha --config config.yaml run

With an example configuration file (see here for more details on settings):

# solana-validator-ha config
validator:
  name: primary-validator # vanity name for logging purposes to identify
                          # this node, its public IP will be auto-detected
                          # and looked up in gossip
  rpc_url: "http://localhost:8899"
  identities:
    active: "/path/to/active-identity.json"   # shared across nodes in the
                                              # validator cluster
    passive: "/path/to/passive-identity.json" # unique to this node

cluster:
  name: mainnet-beta

failover:
  poll_interval_duration: 5s
  leaderless_samples_threshold: 3 # allow up to this number of leaderless
                                  # samples (i.e 15s = poll_interval_duration * leaderless_samples_threshold)
                                  # before considering the validator cluster
                                  # leaderless
  takeover_jitter_duration: 3s # add a random wait between 0 and this
                             # duration to the active command to avoid
                             # before confirming no other peer has become
                             # active when attempting to become active to
                             # avoid race conditions
  peers:
    # vanity names for static IPs identitfying nodes in this validator cluster
    # in gossip, these names are irrelevant and used for logging only
    backup-validator-1:
      ip: 192.168.1.11
    backup-validator-2:
      ip: 192.168.1.12

  active:
    command: "set-identity-with-rollback.sh" # BYO command to become active
    args: [
      "--active-identity-file", "{{ .ActiveIdentityKeypairFile }}",   # template string
                                                                      # referencing value from
                                                                      # validator.identities.active
      "--passive-identity-file", "{{ .PassiveIdentityKeypairFile }}", # template string
                                                                      # referencing value from
                                                                      # validator.identities.passive
    ]
    hooks:
      pre:
        - name: notify-slack
          command: "/path/to/notify-script.sh"
          args: ["--message", "Promoting to active"]

  passive:
    command: "seppukku.sh" # BYO command that makes *damn sure*
                           #this node is passive when it is called
    args: [
      "--passive-identity-file", "{{ .PassiveIdentityKeypairFile }}",
    ]



Summary

By leveraging Solana’s existing gossip protocol for peer discovery and state monitoring, solana-validator-ha provides a simple, robust, and dependency-free solution for high availability validator operations. We have found it to be a good addition to our infrastructure contributing to high levels of uptime and operational resilience through automation.

solana-validator-ha is open source. We welcome contributions and feedback from the community.
